Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: chaoli
  • Model Number: CL-JSXXX-FFN20
  • Usage: Boat, Car, Electric Bicycle, Fan, Home Appliance, Other
  • Certification: CE, ROHS
  • Type: Gear Motor
  • Torque: 14.49gf.cm
  • Construction: Permanent Magnet
  • Commutation: Brush
  • Protect Feature: Totally Enclosed
  • Speed(RPM): 18500r/min
  • Continuous Current(A): 90mA
  • Output Power: 0.48W
  • Voltage(V): 3.0V
  • Efficiency: IE 3
  • Reduction ratio: 10:1/36:1/51:1/73:1/99:1/143:1/211:1/298:1

Packaging & Delivery

Packaging Details Polyfoam or carton seperator inside, strong export carton box outside, with pallet.
Delivery Time 12~25 days
Product Description

1.This product

  • Below are the specifications and structures of the product, for more information, please feel free to contact us.
  • Furthermore, we provide customizable service of micro dc motor/generator, including consulting, design and manufacture services, all the products are made to your order.








Special features/structure:
Motor type: PMDC geared motors
Motor housing (D*F*L): 12*10*24.1mm
Housing material: SECD-O
Shaft (diameter): Φ3.0mm carbon steel (nickel coating)
Way of commutation: carbon-brush/precious metal-brush
Structure: parallel, spur gear and non sealing type
Magnet type: general magnetism/strong magnetism
Rotation: CW/CCW and reversible
Weight: 15g (approx)
Options:
Length and shape for the extended shaft
EMI/EMC suppression
Reduction ratio
Magnet type
Wire diameter and turn number



Key parameters/performance
Rated voltage: 3.0V DC
Reduction ratio: 1:10/1:36/1:51/1:73/1:99/1:143/1:210/1:298
At no load:
Speed: 18500rpm
Current: 0.09A
At maximum efficiency:
Speed: 14371rpm
Current: 0.313A
Torque: 3.2347gf.cm
Output: 0.48W
At stall:
Current: 1.09A (maximum)
Torque: 14.49gf.cm





This product is widely used in: medical equipment, industrial equipment, navigation models, electrical tool and household appliances.

Provide high quality, Bring honorable value.





2.Our products



Following are the main products of our company, including coreless dc motors, brush dc motors, brushless dc motors, flat vibration motors and micro generators, etc., covering a wide range of around 1,000 products.









Our advantages:

.Specialized manufacture

. Complete variety of product

.Volume production ability

.Reasonable pricing with high quality

.Short leading time, customized service





Please send us inquiries table including specifications



for the performance and structure requirements .
